Convert 3d Polyline To 2d Autocad 2018

The flatshot command converts the whole view into a 2d drawing.

Convert 3d polyline to 2d autocad 2018. You can assign elevations to 3d polylines with the feature line elevation commands. Posted january 20 2015. I want to convert some 2d polylines to 3d polyline using the elevetion of the contours. The new polyline will take on the elevation of the start point of the 3d polyline.

The 3d polyline to 2d polyline command was created to convert a large amount of 3d polylines to a. Once in a while a 3d polyline passes by in a 2d drawing. I am searching fot a lisp to select a 2d polyline and convert it to 3d using contours elevetions thanks test1dwg. Use the convert 3d to 2d polylinescommand to convert 3d to 2d polylines.

Under the simplify objects option you can check a box that will convert the 3d polylines into 2d polylines. There are several ways to convert a three dimensional polyline 3dpolyline entity to a standard 2d polyline lwpolyline. Click modify tabdesign panelconvert 3d to 2d polylinesfind. If you want to just cut off the z coordinates of a 3d polyline make it appear 2d use the flatten command express tools to zero all z coordinates.

Without map i dont know an easy way. It can be confusing because the lwpolyline and the old polyline entity used way back in the early days of autocad are both shown as a polyline in the properties window. Click modify tabdesign panelconvert 2d to 3d polylines find. Use the convert 3d to 2d polylines command to convert 3d to 2d polylines.

Select the polyline s to convert. 2d polylines are coplanar objects. The new polyline will take on the elevation of the start point of the 3d polyline. Select the polylines to convert.

If you have autocadmap then go to maptoolsdrawing cleanup. Click modify tab design panel convert 3d to 2d polylines find. Use this utility if you need to modify the elevations of individual vertices of a 2d polyline.
