Use the convert 3d to 2d polylines command to convert 3d to 2d polylines. It can be confusing because the lwpolyline and the old polyline entity used way back in the early days of autocad are both shown as a polyline in the properties window. The flatshot command converts the whole view into a 2d drawing.
convert 3d polyline to 2d autocad lt

To convert 3d polylines to 2d use the convert 3d to 2d polylinescommand to convert 3d to 2d polylines.

Convert 3d polyline to 2d autocad lt. Click modify tab design panel convert 3d to 2d polylines find. Select the polylines to convert. Convert 3d polyline to 2d polyline there are various polyline types in autocad the most common of which is usually the lwpolyline lightweight polyline. Click modify tabdesign panelconvert 2d to 3d polylines find.

The new polyline will take on the elevation of the start point of the 3d polyline. Use the flatten command on the splines if express tools are installed not available for autocad lt see how to install or uninstall express tools in autocad. Click modify tabdesign panelconvert 3d to 2d polylinesfind. Select the polyline s to convert.

You can assign elevations to 3d polylines with the feature line elevation commands. The new polyline will take on the elevation of the start point of the 3d polyline. There are several ways to convert a three dimensional 3dpolyline entity to a standard 2d lightweight polyline lwpolylines. The flatshot command converts the whole view into a 2d drawing.

If you want to just cut off the z coordinates of a 3d polyline make it appear 2d use the flatten command express tools to zero all z coordinates. There are several ways to convert a three dimensional polyline 3dpolyline entity to a standard 2d polyline lwpolyline. If you want to just cut off the z coordinates of a 3d polyline make it appear 2d use the flatten command express tools to zero all z coordinates. How to convert one or more splines to polylines in autocad while specifying the polyline precision.

Note this command is not available in autocad lt so use the alternate method described the alternate method to create a 2d drawing from a 3d model is to. To convert a single spline use the splinedit command. 2d polylines are coplanar objects. Answer if you are using autocad 2007 and higher the flatshot command is available to convert 3d solids to flattened 2d views.

Use this utility if you need to modify the elevations of individual vertices of a 2d polyline. At the command line in autocad type splinedit. Use the convert 2d to 3d polylines command to convert 2d to 3d polylines.
